The TEC-cooled Hypercam 269C Colour camera has a Thermoelectric cooling system for extremely low noise imaging. The 21mp Sony IMX269 is a 12bit colour 4/3rds sensor with 3.30 µm Pixels. The IMX269 Colour sensor is a better replacement for the now discontinued colour Panasonic MN34230 Series for long exposure astrophotography for thos wanting similar image scale and pixel size. The Hypercam features TEC-cooling with 4GB DDR3 RAM, and amp glow reduction for easier image capture and processing. A sealed chamber, and dessicant system with heated optical window make the camera ideal for harsh environments.Due to it's low read noise, the Hypercam 269C PRO TEC camera is suitable for both deepsky and solar system imaging with ROI, as well as "frame stacking and averaging" in other applications. The TEC system can be switched off for fast exposure video imaging.The Hypercam 269C PRO TEC camera has the following features:Features 4GB DDR3 RAM Memory Buffer for better performance. Elimimation of amp glow. We cannot detect any glows on this camera. TEC Cooling system - cools down to -45C below ambient. Temperature sensor, with data available in realtime, temperature written to .FITS files for easier processing. Free offer armoured case. 12v Power supply (specify EU UK or USA cord) ROI (Region of Interest) for cropped higher speed solar, lunar and planetary imaging. Binning supported. SPECIAL OFFER! FREE 1 YEAR SharpCap PRO License! Includes ultra-accurate polar alignment assist, deepsky CMOS exposure time optimisation assist, live stacking for EAA/Video astronomy, live darkframe and flat frame subtrationPlease Download Altair Camera Drivers Here Before plugging in the camera
