StellaMira 125mm ED Doublet f7.8 Refractor Telescope

Product Description

This StellaMira 125mm ED Doublet refractor telescope is from the same stable as the highly regarded StellaMira 90mm ED Triplet. Designed for the discerning visual astronomer or astrophotographer. Boasting a fully multi-coated air-spaced doublet optics with ED glass equal to FPL-53 and Lanthanum deliver high-contrast views with very low chromatic aberration.

The sturdy 2.5" Rack & Pinion dual-speed focuser with 1:10 fine focusing and integral rotator provides excellent load-bearing capacity and smooth, precise focus adjustments. CNC-machined aluminium fittings and a Carbon Fibre tube provide high strength and excellent thermal properties.

A matching 0.8x StellaMira Reducer/Field-Flattener is also available that enables astrophotography at f/6.2 with an evenly illuminated imaging circle large enough for sensor sizes up to and including APS-C.

The price includes CNC tube rings, a Vixen-style dovetail mounting bar (not the Losmandy-style bar shown in photos), a carry handle, and a custom-designed Oklop carry case.

Features
125mm Aperture
f/7.8 focal ratio / 975mm focal length
Doublet optics with an ED glass lens (equal to FPL-53) and Lanthanum
Fully multi-coated optics for maximum light transmission and high contrast
Strong Carbon Fibre tube with excellent thermal properties
CNC-machined aluminium fittings
2.5" Dual-speed Rack & Pinion focuser
1:10 Fine Focus mechanism
360º Camera Angle Adjuster (CAA)
Non-marring brass compression rings (2" clamp and 2" to 1.25" adapter clamp) for a strong and secure connection
Fitted with a Synta-style finder shoe
Supplied with tube rings, carry handle and Vixen-style dovetail
Additional M6 threaded holes on the dovetail, handle and tube rings
Includes a custom-designed Oklop carry case

Dimensions
Tube length (dew-shield retracted): 885mm
Tube length (dew-shield extended): 1000 mm
Tube diameter: 131 mm
Dew-shield external diameter: 156 mm
Focuser adjustment range: 95 mm
Tube weight: 4.7 kg
Tube weight with rings/dovetail/handle: 5.8 kg

Specifications
Type Refractor
Aperture 125mm
Focal Length 975mm
Focal Ratio f/7.8
Optical Construction
Air spaced doublet 1x ED lens (equivalent to FPL-53) & 1x Lanthanum lens
Lens Coating Fully multi-coated
Tube Material Carbon FIbre & Aluminium
Focuser 2.5" Rack & Pinion Dual Speed
Fine Focuser 1:10
Focuser Thread M63x1 Female with 2" eyepiece holder removed
Accessories Tube Rings, Vixen-type Dovetail & Handle
Case Custom-designed Oklop soft carry case
