Home Astro-Imaging CCD & CMOS Cameras Altair Astronomy Cameras Altair Hypercam 26C APS-C Colour Camera 16bit
The new standard in astro imaging, Altair Hypercam 26C uses the latest 16bit Sony IMX571 sensor with ultra low read noise and super high quantum efficiency in a large APS-C format. BBC Sky at Night Magazine 4.5 Stars "The Altair Hypercam 26C APS-C colour 16-bit is a highly capable camera with a high-performing sensor that excels at deep-sky astrophotography."For many, this will be the final camera to own for astro imaging. 26mp APS-C size Back Illuminated Sony IMX571 sensor 16bit ADC yields 65,536 grey levels in the image Zero Amp Glow Special Ultra Low Read Noise mode * True Hardware Binning 2 Stage TEC Cooling Heated Optical Window 2 year warranty, with no sensor frosting guarantee** Rear USB2.0 hub 2x ports 12v power is required to run this camera Supplied with armoured case 240~110v compatible 12v DC power supply with UK plug Software & drivers downloadable at www.altairastro.helpHypercam 26C Specifications:USB Interface USB3.1, USB3.0, USB2.0, Type-B socketSensor Colour Sony IMX571Resolution 26mp 6224 x 4168pxPixel Size 3.76 umImage Area 23.4mm x 15.7mmSensor Diagonal 28.3 mmSensor Protection Window UVIR Block, AR CoatingShutter RollingRead Noise 2.6 - 1.14 e-Ultra Low Noise Mode 2.35 - 1.16 e-Qe Approx. 80% PeakFull Well Capacity 51ke-ADC 8bit 16bitCooling TEC, -35C below ambientMax Frame Rate @ Full Resolution 6.8 FPS 16bit - 13.2FPS 8bitDDR Memory 512mb2x USB2.0 PortsRegion Of Interest RoiSNR Max 47.1 dBDynamic Range 86.8 dB (Ultra Low Noise Mode)Exposure range 0.1ms 3600secsHCG Mode/ LCG Mode SupportCamera front flange thread M42x075mm FemaleSensor to flange distance 17.5mmTEC Power input 12.0v-13.0v DC* requires 12v power.** for two years from delivery date, normal use, not applicable if camera sensor chamber is breached.
Great camera - great price Ive been wanting an IMX571 for a while. Gain 100 seems to be fine for DSO. Same BF as ZWO. This new model (not pictured) takes a bolt on ZWO EFW (2in). I use the rings from my ASI294 to get 55mm. Works out of box with both N.I.N.A and Kstars using native drivers (5 sessions already). Top marks. (12/09/2023) nick - merseyside
